- Snap action switch
- Cast aluminum reservoir
- Integral junction box
- 6-ft cord and plug
- Stainless-steel shaft
- Thermally protected motor
- Only suitable for 60Hz operation; Imperial Thread versions only
SPECIFICATIONS | AL2 |
Motor: (hp @ rpm) | 1/10 @ 3000 |
Electrical | 115V 3.1A |
Electrical | 230V 1.5A |
Inlet Size | 1-3/8″ |
Discharge Size | 3/8” FNTP |
Reservoir Capacity | 2 gallon |
Unit Dimensions (WxDxH) | 12”x9”x10” |
Maximum Temperature | 150°F |
Sealed Reservoir | No |
Weight | 15 lbs. |
PUMP PERFORMANCE | |
Lift (feet) | Flow (gph) |
6 | 185 |
12 | 139 |
16 | 79 |
20 | 51 |
Maximum Lift | 22 feet |
